Heavy Duty All-In-One Commercial Door Closer with FlexPlate
SKU UH4071
- Features - This heavy duty closer controls the traffic in and out of your space and automatically closes the door after every opening. Included FlexPlate adapts to the existing holes in your door for easy replacement of an old or broken door closer.
- Measurements - For exterior doors up to 250 lbs. and 48” wide and interior doors up to 250 lbs. and 60” wide
- Specifications - This closer meets ANSI Grade 1 requirements, is ADA compliant, and has a 180-degree opening range. The adjustable spring tension powers this closer from a Size 1 to a Size 6 to provide adjustment for light to heavy applications.
- Installation - Compatible with most commercial doors, and can be utilized in standard, top jamb, and parallel mounting applications. Included FlexPlate adapts to 80% of door closers hole patterns in the market for easy door closer replacement.
- Universal Hardware is the pro's choice for commercial door hardware and flat goods.
Product Description
The Universal Hardware Heavy Duty Aluminum Door Closer with FlexPlate™ delivers strength, versatility, and ease of installation for professionals. The patent-pending FlexPlate™ system simplifies retrofitting by adapting to most existing hole patterns—no drilling additional holes. The plate and four adjustable sliders conform to nearly every door closer mounting configuration on the market. With adjustable spring tension (Size 1 to 6), this closer supports applications ranging from light interior doors to heavy-duty commercial use. Fine-tune performance with fully adjustable sweep speed, latching speed, and backcheck. Compatible mounting methods include regular arm, parallel arm, and top jamb installations.
Videos
Additional Images
Mounting Configurations
Product Information
Item Details
- Category
- Door Closers
- Fineline
- Commercial Closer
- Color
- Aluminum
- Fineline
- Commercial Closer
- Mount Type
- Standard, Top Jamb, Parallel
- Interior Door Compatibility
- Left or right hinged doors up to 250 lbs. and 60" wide
- Exterior Door Compatibility
- Left or right hinged doors up to 250 lbs. and 48" wide
- Closer Rating
- Adjustable Size 1-6
- OpeningRange
- 180 Degrees
- Mount Type
- Standard, Top Jamb, Parallel
- Warranty
- 10 Year Limited Warranty
- UPC
- 039208251433
